Low price for Soldering Oven Smd - 1.2m automatic printing machine – GUS Detail:

Automatic vision solder paste printing machine L12

Key points of product technology:

• Humanized design

• Optimization of production lens / LED lighting products

• Unique spray type automatic cleaning system

• Efficient and energy-saving structure of paper for wiping test

• Unique image processing system

• Intelligent printing production mode

• lPrinting range: 1200 * 350mm

• External dimension of the machine: 2200 × 1200 × 1500mm

Item		G-L12
Screen Frames	Min Size	737*300mm
	Max Size	1500*750mm
	Thickness	25~40mm
PCB Min Size		80*-50mm
PCB Max Size		1200*350mm
PCB Thickness		0.4~6mm
PCB Warpage		＜1%
Transport Height		900±40mm
Transport Direction		Left-Right;Right-Left;Left-Left;Right-Right
Transport Speed		Max 1500mm/S Programmable
Board Location PCB	Support System	Magnetic Pin/Up-down table adjusted/supportblock by hand
	Clamping System	side clamping,vacuum nozzle
Print head		Two independent motorised printheads
Squeegee Speed		6~200mm/sec
Squeegee Pressure		0~15Kg
Squeegee Angle		60°/55°/45°
Squeegee Type		Stainless steel(Standard), plastic
Stencil Separation Speed		0.1~20mm/sec Programmable
Cleaning System		Dry、Wet、Vacuum (Programmable)
Table Adjustment ranges		X:±10mm;Y:±10mm;θ:±2°
Machine
Repeat Position Accuracy		±0.015mm
Printing Accuracy		±0.03mm
Cycle Time		<15S (Exclude Printing & Cleaning)
Product Changeover		<5Min
Air Required		4.5~6Kg/cm²
Power Input		AC:220±10%,50/60HZ 1Φ 3KW
Control Method		PC Control
Machine Dimensions		2200(L)X1200(W)X1500(H)mm
Machine Weight		Approx:1500Kg

1.2M AUTOMATIC PRINTING MACHINE
